HC-Cargo Generator
HC-Cargo Generator
Vare nr.: F032115860

HC-Cargo Generator

Tekniske oplysninger:

Spænding: 14, Amp: 150, Rotation: CW, Monteringsbeslag forfordelingsdæksel: 76,00

Beskrivelse

BMW Generator 12V-150A, 6st 12V - 150A, 6st, (BSS) for Yourex produktordre 90-040-9621

Spænding: 14
Ampere: 150
Remskive afstand: 61,00
Bredde/løftearmsafstand: 28,00
monteringsbeslag afstand: 76,00
Beslagshul: 10,50
Bælte justering beslaghul position: 45
Bælte justering beslaghul 1: 10,50
Remskive dia.: 53,50
Riller/remskive: 6
Radius: 92,00
Radius 2: 92,00
B+: M8
Position/B+ i min.: 52
Rotation: CW
Stiknummer: PL86
Total længde mm: 181,00
Terminaltype: COM
Kommunikation: BSS
Remskive: SP
Regulator type: IR
Produktinfo: BN
Bemærkninger: Denne generator har en COM terminal på regulatoren. Det anbefales at bruge OEM-nummeret til at kontrollere egnethed, inden der bestilles.

Filer

Specifikation

B+ M8
Communication BSS
Mount. bracket dist. 76.00
Belt. adj. bracket hole 1 10.50
Belt. adj. brackethole pos. 45
Plug no. PL86
Bracket hole 10.50
Position/B+ in min. 52
Prod. info BN
Pulley SP
Pulley dia. 53.50
Pulley dist. 61.00
Radius 92.00
Radius 2 92.00
Regulator type IR
Remarks This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.
Rotation CW
Grooves/pulley 6
Terminal type COM
Voltage 14
Total length 181.00 mm
Width/holder arm 28.00
Amp 150

  • OEM
    a3198, A3198, A3198(VALEO), A3198S, CAL15387, DRA0691, F032115860, LRA03415, TG15C 072, tg15c072, 28-6527, 215.147.1502, 215.558.150, 1231 7800308, 1231 7802928, 1986A00604, 1986A00736, 2051ir, 24116N, 24116N-OS, 115860, 209229, 209229A, 439621, 440179, 2543309, 2543309C, 2543309D, 7800308, 7802928, 9090852, 12060992, 32440179, 0986084680, 12317800308, 12317802928

  • Konkurrentreferens
    a3198, A3198(VALEO), A3198S, CAL15387, DRA0691, LRA03415, 28-6527, 215.147.1502, 215.558.150, 24116N, 24116N-OS, 209229, 209229A, 439621, 440179, 9090852, 12060992, 32440179, 0986084680

  • Bilmärken
    BMW

  • NormaliseratArtNr
    a3198, a3198s, a3198valeo, cal15387, dra0691, f032115860, lra03415, tg15c072, 1986a00604, 1986a00736, 2051ir, 24116n, 24116nos, 115860, 209229, 209229a, 286527, 439621, 440179, 2543309, 2543309c, 2543309d, 7800308, 7802928, 9090852, 12060992, 32440179, 215558150, 0986084680, 2151471502, 12317800308, 12317802928

  • Passar modeller
    BMW 3 (E90) 325 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.06-02.10
    BMW 3 (E90) 330 d Engine volume: 3.0 Engine type: N57 D30 A Year: 09.08-10.11
    BMW 3 (E90) 330 d xDrive Engine volume: 3.0 Engine type: N57 D30 A Year: 09.08-10.11
    BMW 3 (E90) 335 d Engine volume: 3.0 Engine type: M57 D30 (306D5) Year: 09.06-12.11
    BMW 3 Cabriolet (E93) 330 d Engine volume: 3.0 Engine type: N57 D30 A Year: 01.09-09.13
    BMW 3 Coupé (E92) 330 d Engine volume: 3.0 Engine type: N57 D30 A Year: 01.09-06.13
    BMW 3 Coupé (E92) 330 d xDrive Engine volume: 3.0 Engine type: N57 D30 A Year: 02.10-06.13
    BMW 3 Coupé (E92) 330 xd Engine volume: 3.0 Engine type: N57 D30 A Year: 03.08-02.10
    BMW 3 Coupé (E92) 335 d Engine volume: 3.0 Engine type: M57 D30 (306D5) Year: 03.06-03.13
    BMW 3 Touring (E91) 325 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.06-06.12
    BMW 3 Touring (E91) 330 d Engine volume: 3.0 Engine type: N57 D30 A Year: 02.08-05.12
    BMW 3 Touring (E91) 330 d xDrive Engine volume: 3.0 Engine type: N57 D30 A Year: 01.09-06.12
    BMW 3 Touring (E91) 335 d Engine volume: 3.0 Engine type: M57 D30 (306D5) Year: 09.06-06.12
    BMW 5 (E60) 520 d Engine volume: 2.0 Engine type: M47 D20 (204D4) Year: 09.05-02.07
    BMW 5 (E60) 520 d Engine volume: 2.0 Engine type: M47 D20 (204D4), N47 D20 A, N47 D20 C Year: 09.05-12.09
    BMW 5 (E60) 525 d Engine volume: 2.5 Engine type: M57 D25 (256D2) Year: 06.04-03.10
    BMW 5 (E60) 525 d Engine volume: 2.5 Engine type: M57 D25 (256D2) Year: 12.04-03.10
    BMW 5 (E60) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D2) Year: 09.02-09.05
    BMW 5 (E60) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D2), M57 D30 (306D3) Year: 09.02-12.09
    BMW 5 (E60) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 02.07-12.09
    BMW 5 (E60) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.05-03.07
    BMW 5 (E60) 530 d xDrive Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.07-12.09
    BMW 5 (E60) 530 xd Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 02.05-02.07
    BMW 5 (E60) 530 xd Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 03.07-08.07
    BMW 5 (E60) 535 d Engine volume: 3.0 Engine type: M57 D30 (306D4) Year: 09.04-03.10
    BMW 5 Touring (E61) 520 d Engine volume: 2.0 Engine type: M47 D20 (204D4) Year: 09.05-02.07
    BMW 5 Touring (E61) 520 d Engine volume: 2.0 Engine type: M47 D20 (204D4), N47 D20 A, N47 D20 C Year: 04.05-05.10
    BMW 5 Touring (E61) 525 d Engine volume: 2.5 Engine type: M57 D25 (256D2) Year: 03.04-03.07
    BMW 5 Touring (E61) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D2) Year: 03.04-09.05
    BMW 5 Touring (E61) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D2), M57 D30 (306D3) Year: 03.04-05.10
    BMW 5 Touring (E61) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 02.05-02.07
    BMW 5 Touring (E61) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 02.07-05.10
    BMW 5 Touring (E61) 530 d xDrive Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.07-05.10
    BMW 5 Touring (E61) 530 xd Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 02.05-02.07
    BMW 5 Touring (E61) 530 xd Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 03.07-08.07
    BMW 5 Touring (E61) 535 d Engine volume: 3.0 Engine type: M57 D30 (306D4) Year: 09.04-12.10
    BMW 7 (E65, E66, E67) 730 d Engine volume: 3.0 Engine type: M57 D30 (306D2) Year: 06.02-02.05
    BMW 7 (E65, E66, E67) 730 d Engine volume: 3.0 Engine type: M57 D30 (306D2) Year: 09.02-08.03
    BMW 7 (E65, E66, E67) 730 d Engine volume: 3.0 Engine type: M57 D30 (306D2), M57 D30 (306D3) Year: 09.03-08.08
    BMW 7 (E65, E66, E67) 730 Ld Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 07.05-08.08
    BMW X3 (E83) 3.0 d Engine volume: 3.0 Engine type: M57 D30 (306D2) Year: 01.04-08.05
    BMW X3 (E83) 3.0 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.05-08.08
    BMW X3 (E83) 3.0 sd Engine volume: 3.0 Engine type: M57 D30 (306D5) Year: 09.06-08.08
    BMW X3 (E83) xDrive 30 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.08-08.10
    BMW X3 (E83) xDrive 35 d Engine volume: 3.0 Engine type: M57 D30 (306D5) Year: 09.08-08.11
    1 / 9
  • Beskrivelse
    BMW Generator 12V-150A, 6st 12V - 150A, 6st, (BSS) for Yourex produktordre 90-040-9621

    Spænding: 14
    Ampere: 150
    Remskive afstand: 61,00
    Bredde/løftearmsafstand: 28,00
    monteringsbeslag afstand: 76,00
    Beslagshul: 10,50
    Bælte justering beslaghul position: 45
    Bælte justering beslaghul 1: 10,50
    Remskive dia.: 53,50
    Riller/remskive: 6
    Radius: 92,00
    Radius 2: 92,00
    B+: M8
    Position/B+ i min.: 52
    Rotation: CW
    Stiknummer: PL86
    Total længde mm: 181,00
    Terminaltype: COM
    Kommunikation: BSS
    Remskive: SP
    Regulator type: IR
    Produktinfo: BN
    Bemærkninger: Denne generator har en COM terminal på regulatoren. Det anbefales at bruge OEM-nummeret til at kontrollere egnethed, inden der bestilles.

    Filer

  • Specifikation
    B+ M8
    Communication BSS
    Mount. bracket dist. 76.00
    Belt. adj. bracket hole 1 10.50
    Belt. adj. brackethole pos. 45
    Plug no. PL86
    Bracket hole 10.50
    Position/B+ in min. 52
    Prod. info BN
    Pulley SP
    Pulley dia. 53.50
    Pulley dist. 61.00
    Radius 92.00
    Radius 2 92.00
    Regulator type IR
    Remarks This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.
    Rotation CW
    Grooves/pulley 6
    Terminal type COM
    Voltage 14
    Total length 181.00 mm
    Width/holder arm 28.00
    Amp 150
  • Køretøjsmatchning

    • OEM
      a3198, A3198, A3198(VALEO), A3198S, CAL15387, DRA0691, F032115860, LRA03415, TG15C 072, tg15c072, 28-6527, 215.147.1502, 215.558.150, 1231 7800308, 1231 7802928, 1986A00604, 1986A00736, 2051ir, 24116N, 24116N-OS, 115860, 209229, 209229A, 439621, 440179, 2543309, 2543309C, 2543309D, 7800308, 7802928, 9090852, 12060992, 32440179, 0986084680, 12317800308, 12317802928

    • Konkurrentreferens
      a3198, A3198(VALEO), A3198S, CAL15387, DRA0691, LRA03415, 28-6527, 215.147.1502, 215.558.150, 24116N, 24116N-OS, 209229, 209229A, 439621, 440179, 9090852, 12060992, 32440179, 0986084680

    • Bilmärken
      BMW

    • NormaliseratArtNr
      a3198, a3198s, a3198valeo, cal15387, dra0691, f032115860, lra03415, tg15c072, 1986a00604, 1986a00736, 2051ir, 24116n, 24116nos, 115860, 209229, 209229a, 286527, 439621, 440179, 2543309, 2543309c, 2543309d, 7800308, 7802928, 9090852, 12060992, 32440179, 215558150, 0986084680, 2151471502, 12317800308, 12317802928

    • Passar modeller
      BMW 3 (E90) 325 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.06-02.10
      BMW 3 (E90) 330 d Engine volume: 3.0 Engine type: N57 D30 A Year: 09.08-10.11
      BMW 3 (E90) 330 d xDrive Engine volume: 3.0 Engine type: N57 D30 A Year: 09.08-10.11
      BMW 3 (E90) 335 d Engine volume: 3.0 Engine type: M57 D30 (306D5) Year: 09.06-12.11
      BMW 3 Cabriolet (E93) 330 d Engine volume: 3.0 Engine type: N57 D30 A Year: 01.09-09.13
      BMW 3 Coupé (E92) 330 d Engine volume: 3.0 Engine type: N57 D30 A Year: 01.09-06.13
      BMW 3 Coupé (E92) 330 d xDrive Engine volume: 3.0 Engine type: N57 D30 A Year: 02.10-06.13
      BMW 3 Coupé (E92) 330 xd Engine volume: 3.0 Engine type: N57 D30 A Year: 03.08-02.10
      BMW 3 Coupé (E92) 335 d Engine volume: 3.0 Engine type: M57 D30 (306D5) Year: 03.06-03.13
      BMW 3 Touring (E91) 325 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.06-06.12
      BMW 3 Touring (E91) 330 d Engine volume: 3.0 Engine type: N57 D30 A Year: 02.08-05.12
      BMW 3 Touring (E91) 330 d xDrive Engine volume: 3.0 Engine type: N57 D30 A Year: 01.09-06.12
      BMW 3 Touring (E91) 335 d Engine volume: 3.0 Engine type: M57 D30 (306D5) Year: 09.06-06.12
      BMW 5 (E60) 520 d Engine volume: 2.0 Engine type: M47 D20 (204D4) Year: 09.05-02.07
      BMW 5 (E60) 520 d Engine volume: 2.0 Engine type: M47 D20 (204D4), N47 D20 A, N47 D20 C Year: 09.05-12.09
      BMW 5 (E60) 525 d Engine volume: 2.5 Engine type: M57 D25 (256D2) Year: 06.04-03.10
      BMW 5 (E60) 525 d Engine volume: 2.5 Engine type: M57 D25 (256D2) Year: 12.04-03.10
      BMW 5 (E60) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D2) Year: 09.02-09.05
      BMW 5 (E60) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D2), M57 D30 (306D3) Year: 09.02-12.09
      BMW 5 (E60) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 02.07-12.09
      BMW 5 (E60) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.05-03.07
      BMW 5 (E60) 530 d xDrive Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.07-12.09
      BMW 5 (E60) 530 xd Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 02.05-02.07
      BMW 5 (E60) 530 xd Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 03.07-08.07
      BMW 5 (E60) 535 d Engine volume: 3.0 Engine type: M57 D30 (306D4) Year: 09.04-03.10
      BMW 5 Touring (E61) 520 d Engine volume: 2.0 Engine type: M47 D20 (204D4) Year: 09.05-02.07
      BMW 5 Touring (E61) 520 d Engine volume: 2.0 Engine type: M47 D20 (204D4), N47 D20 A, N47 D20 C Year: 04.05-05.10
      BMW 5 Touring (E61) 525 d Engine volume: 2.5 Engine type: M57 D25 (256D2) Year: 03.04-03.07
      BMW 5 Touring (E61) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D2) Year: 03.04-09.05
      BMW 5 Touring (E61) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D2), M57 D30 (306D3) Year: 03.04-05.10
      BMW 5 Touring (E61) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 02.05-02.07
      BMW 5 Touring (E61) 530 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 02.07-05.10
      BMW 5 Touring (E61) 530 d xDrive Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.07-05.10
      BMW 5 Touring (E61) 530 xd Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 02.05-02.07
      BMW 5 Touring (E61) 530 xd Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 03.07-08.07
      BMW 5 Touring (E61) 535 d Engine volume: 3.0 Engine type: M57 D30 (306D4) Year: 09.04-12.10
      BMW 7 (E65, E66, E67) 730 d Engine volume: 3.0 Engine type: M57 D30 (306D2) Year: 06.02-02.05
      BMW 7 (E65, E66, E67) 730 d Engine volume: 3.0 Engine type: M57 D30 (306D2) Year: 09.02-08.03
      BMW 7 (E65, E66, E67) 730 d Engine volume: 3.0 Engine type: M57 D30 (306D2), M57 D30 (306D3) Year: 09.03-08.08
      BMW 7 (E65, E66, E67) 730 Ld Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 07.05-08.08
      BMW X3 (E83) 3.0 d Engine volume: 3.0 Engine type: M57 D30 (306D2) Year: 01.04-08.05
      BMW X3 (E83) 3.0 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.05-08.08
      BMW X3 (E83) 3.0 sd Engine volume: 3.0 Engine type: M57 D30 (306D5) Year: 09.06-08.08
      BMW X3 (E83) xDrive 30 d Engine volume: 3.0 Engine type: M57 D30 (306D3) Year: 09.08-08.10
      BMW X3 (E83) xDrive 35 d Engine volume: 3.0 Engine type: M57 D30 (306D5) Year: 09.08-08.11
      1 / 9
