HC-Cargo Generator
HC-Cargo Generator
Vare nr.: F032116597

HC-Cargo Generator

Tekniske oplysninger:

Spænding: 14, Amp: 180, Montagebeslag afstand.: 44,50, Remskivens diameter.: 54,00

Beskrivelse

Generator 12V-180A 12V - 180A, 6gr.frg, (LIN) Friløbsremskive = 45-252-0263 For Yourrex produktordre 90-258-4636

Voltage: 14
Amp: 180
Remskive diameter: 43.00
Fastgørelsesbeslag afstand: 44.50
Beslagshul: 10.20
Remjusteringsbeslaghuls position: 47
Remjusteringsbeslaghuls 1: 10.50
Remskivens diameter: 54.00
Riller/remskive: 6
Radius: 90.00
Radius 2: 93.00
B+: M8
Position/B+ i min.: 60
Stik nr.: PL174
Samlet længde mm: 189.00
ID-kode: 28
Kommunikation: LIN_1
Remskive: SP/FW
Blæser: IF
Regulator type: IR

Filer

Specifikation

B+ M8
Communication LIN_1
Mount. bracket dist. 44.50
Belt. adj. bracket hole 1 10.50
Belt. adj. brackethole pos. 47
Plug no. PL174
Bracket hole 10.20
Position/B+ in min. 60
Pulley SP/FW
Pulley dia. 54.00
Pulley dist. 43.00
Radius 90.00
Radius 2 93.00
Regulator type IR
Fan IF
Grooves/pulley 6
ID Code 28
Voltage 14
Total length 189.00 mm
Amp 180

  • OEM
    BJ32-10300AC, BJ32-10300AD, BJ3210300AC, BJ3210300AD, C2Z-17063, C2Z-31658, C2Z17063, C2Z31658, DAN 1111, F032116597, LR 028116, LR 031026, LR028116, LR031026, 0986 085 120, 1986A00640, 104210-6360, 104210-6361, 116597

  • Konkurrentreferens
    A6434(DENSO), A6434S, CAL40399, DAN1111, DRA1326, LRA03624, 8EL011713-181, 28-6734, 214.179.1802, 455.532.180, 209324, 209324A, 440763, 553760RI, 12090755, 32118821, 0986085120

  • Bilmärken
    Jaguar, Land Rover

  • NormaliseratArtNr
    a6434denso, a6434s, bj3210300ac, bj3210300ad, c2z17063, c2z31658, cal40399, dan1111, dra1326, f032116597, lr028116, lr031026, lra03624, 8el011713181, 1986a00640, 116597, 209324, 209324a, 286734, 440763, 553760ri, 12090755, 32118821, 455532180, 0986085120, 1042106360, 1042106361, 2141791802

  • Passar modeller
    Jaguar Model: XF Model series: XF Sportbrake Model type: Sportbrake Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Type description: CC9 Body: Estate From date: 01-09-2012 To date: 01-04-2014 Fuel: Diesel Approved: Yes
    Jaguar Model: XF Model series: XF Sportbrake Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Body: Estate From date: 01-09-2012 To date: 01-04-2014 Fuel: Diesel Approved: Yes
    Jaguar Model: XF Model series: XF Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Type description: _J05_, CC9 From date: 01-03-2012 To date: 01-04-2015 Fuel: Diesel Approved: Yes
    Jaguar Model: XF Model series: XF Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Type description: _J05_, CC9 From date: 01-05-2011 To date: 01-04-2015 Fuel: Diesel Approved: Yes
    Jaguar Series: XF (X250) Model: 2.2 D Engine volume: 2.2 Engine type: 224DT Year: 03.12-04.15
    Jaguar Series: XF (X250) Model: 2.2D Engine volume: 2.2 Engine type: 224DT Year: 04.11-04.15
    Jaguar Series: XF Sportbrake Model: 2.2 D Engine volume: 2.2 Engine type: 224DT Year: 09.12-04.14
    Land Rover Model: Range Rover Evoque Model series: Range Rover Evoque Model type: ED4 Size of motor: 2.2 Brand of engine: 224DT From date: 01-06-2011 Fuel: Diesel Approved: Yes
    Land Rover Model: Range Rover Evoque Model series: Range Rover Evoque Model type: SD4 Size of motor: 2.2 Brand of engine: 224DT From date: 01-06-2011 Fuel: Diesel Approved: Yes
    Land Rover Model: Range Rover Evoque Model series: Range Rover Evoque Model type: TD4 Type of engine: TD Size of motor: 2.2 Brand of engine: 224DT From date: 01-06-2011 Fuel: Diesel Approved: Yes
    Land Rover Model: Range Rover Model series: Range Rover Evoque Model type: 4X4 Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Type description: L538 Body: Box Body / Estate From date: 01-05-2015 To date: 01-12-2019 Fuel: Diesel Approved: Yes
    Land Rover Model: Range Rover Model series: Range Rover Evoque Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Type description: L538 Body: Box Body / Estate From date: 01-05-2015 To date: 01-12-2019 Fuel: Diesel Approved: Yes
    Land Rover Series: Range - Rover Evoque Model: 2.2 D 4x4 Engine volume: 2.2 Engine type: 224DT Year: 06.11-12.19
    Land Rover Series: Range - Rover Evoque Model: 2.2 D Engine volume: 2.2 Engine type: 224DT Year: 06.11-12.19
    1 / 3
  • Beskrivelse
    Generator 12V-180A 12V - 180A, 6gr.frg, (LIN) Friløbsremskive = 45-252-0263 For Yourrex produktordre 90-258-4636

    Voltage: 14
    Amp: 180
    Remskive diameter: 43.00
    Fastgørelsesbeslag afstand: 44.50
    Beslagshul: 10.20
    Remjusteringsbeslaghuls position: 47
    Remjusteringsbeslaghuls 1: 10.50
    Remskivens diameter: 54.00
    Riller/remskive: 6
    Radius: 90.00
    Radius 2: 93.00
    B+: M8
    Position/B+ i min.: 60
    Stik nr.: PL174
    Samlet længde mm: 189.00
    ID-kode: 28
    Kommunikation: LIN_1
    Remskive: SP/FW
    Blæser: IF
    Regulator type: IR

    Filer

  • Specifikation
    B+ M8
    Communication LIN_1
    Mount. bracket dist. 44.50
    Belt. adj. bracket hole 1 10.50
    Belt. adj. brackethole pos. 47
    Plug no. PL174
    Bracket hole 10.20
    Position/B+ in min. 60
    Pulley SP/FW
    Pulley dia. 54.00
    Pulley dist. 43.00
    Radius 90.00
    Radius 2 93.00
    Regulator type IR
    Fan IF
    Grooves/pulley 6
    ID Code 28
    Voltage 14
    Total length 189.00 mm
    Amp 180
  • Køretøjsmatchning

    • OEM
      BJ32-10300AC, BJ32-10300AD, BJ3210300AC, BJ3210300AD, C2Z-17063, C2Z-31658, C2Z17063, C2Z31658, DAN 1111, F032116597, LR 028116, LR 031026, LR028116, LR031026, 0986 085 120, 1986A00640, 104210-6360, 104210-6361, 116597

    • Konkurrentreferens
      A6434(DENSO), A6434S, CAL40399, DAN1111, DRA1326, LRA03624, 8EL011713-181, 28-6734, 214.179.1802, 455.532.180, 209324, 209324A, 440763, 553760RI, 12090755, 32118821, 0986085120

    • Bilmärken
      Jaguar, Land Rover

    • NormaliseratArtNr
      a6434denso, a6434s, bj3210300ac, bj3210300ad, c2z17063, c2z31658, cal40399, dan1111, dra1326, f032116597, lr028116, lr031026, lra03624, 8el011713181, 1986a00640, 116597, 209324, 209324a, 286734, 440763, 553760ri, 12090755, 32118821, 455532180, 0986085120, 1042106360, 1042106361, 2141791802

    • Passar modeller
      Jaguar Model: XF Model series: XF Sportbrake Model type: Sportbrake Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Type description: CC9 Body: Estate From date: 01-09-2012 To date: 01-04-2014 Fuel: Diesel Approved: Yes
      Jaguar Model: XF Model series: XF Sportbrake Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Body: Estate From date: 01-09-2012 To date: 01-04-2014 Fuel: Diesel Approved: Yes
      Jaguar Model: XF Model series: XF Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Type description: _J05_, CC9 From date: 01-03-2012 To date: 01-04-2015 Fuel: Diesel Approved: Yes
      Jaguar Model: XF Model series: XF Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Type description: _J05_, CC9 From date: 01-05-2011 To date: 01-04-2015 Fuel: Diesel Approved: Yes
      Jaguar Series: XF (X250) Model: 2.2 D Engine volume: 2.2 Engine type: 224DT Year: 03.12-04.15
      Jaguar Series: XF (X250) Model: 2.2D Engine volume: 2.2 Engine type: 224DT Year: 04.11-04.15
      Jaguar Series: XF Sportbrake Model: 2.2 D Engine volume: 2.2 Engine type: 224DT Year: 09.12-04.14
      Land Rover Model: Range Rover Evoque Model series: Range Rover Evoque Model type: ED4 Size of motor: 2.2 Brand of engine: 224DT From date: 01-06-2011 Fuel: Diesel Approved: Yes
      Land Rover Model: Range Rover Evoque Model series: Range Rover Evoque Model type: SD4 Size of motor: 2.2 Brand of engine: 224DT From date: 01-06-2011 Fuel: Diesel Approved: Yes
      Land Rover Model: Range Rover Evoque Model series: Range Rover Evoque Model type: TD4 Type of engine: TD Size of motor: 2.2 Brand of engine: 224DT From date: 01-06-2011 Fuel: Diesel Approved: Yes
      Land Rover Model: Range Rover Model series: Range Rover Evoque Model type: 4X4 Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Type description: L538 Body: Box Body / Estate From date: 01-05-2015 To date: 01-12-2019 Fuel: Diesel Approved: Yes
      Land Rover Model: Range Rover Model series: Range Rover Evoque Type of engine: Diesel Size of motor: 2.2 Brand of engine: 224DT Type description: L538 Body: Box Body / Estate From date: 01-05-2015 To date: 01-12-2019 Fuel: Diesel Approved: Yes
      Land Rover Series: Range - Rover Evoque Model: 2.2 D 4x4 Engine volume: 2.2 Engine type: 224DT Year: 06.11-12.19
      Land Rover Series: Range - Rover Evoque Model: 2.2 D Engine volume: 2.2 Engine type: 224DT Year: 06.11-12.19
      1 / 3
