HC-Cargo Generator
HC-Cargo Generator
Vare nr.: F032115835

HC-Cargo Generator

Tekniske oplysninger:

Spænding: 14, Amp: 120, Rotation: CW, Monteringsbeslag afstand.: 82,00

Beskrivelse

Spænding: 14
Amp: 120
Skive dist.: 32.00
Bredde/holderarms: 14.00
Monteringsbeslag dist.: 82.00
Beslagshuls: 10.50
Bælte. justering beslagshuls pos.: 50
Bælte. justering beslagshuls 1: M10
Skive diameter: 53.00
Riller/skive: 6
Radius: 92.00
Radius 2: 96.00
B+: M8
Pos. / B+ i min.: 30
D+ Størrelse: Stik
Rotation: CW
Stik nr.: PL61
Total længde mm: 187.00
Terminaltype: L-DFM
Skive: SP/FW
Regulator type: IR
Produktoplysninger: BN

Filer

Specifikation

B+ M8
Mount. bracket dist. 82.00
Belt. adj. bracket hole 1 M10
Belt. adj. brackethole pos. 50
Plug no. PL61
Bracket hole 10.50
Position/B+ in min. 30
Prod. info BN
Pulley SP/FW
Pulley dia. 53.00
Pulley dist. 32.00
Radius 92.00
D+ Size Plug
Radius 2 96.00
Regulator type IR
Rotation CW
Grooves/pulley 6
Terminal type L-DFM
Voltage 14
Total length 187.00 mm
Width/holder arm 14.00
Amp 120

  • OEM
    F032115835, 1986A00847, 24436554, 0124515072, 0124515073, 9966030122U, 9966030122X, 99660301202, 99660301204, 99660301206

  • Konkurrentreferens
    A0486, CAL10287, DRB6520, LRA02859, 28-4975, 211.316.1202, 485.502.120, 11041N, 11041R, 209414, 209414A, 444240, 9046520, 12044450, 12046520, 0986046520, 0986046523, 0986046527

  • NormaliseratArtNr
    a0486, cal10287, drb6520, f032115835, lra02859, 1986a00847, 11041n, 11041r, 209414, 209414a, 284975, 444240, 9046520, 12044450, 12046520, 24436554, 0124515072, 0124515073, 485502120, 0986046520, 0986046523, 0986046527, 2113161202, 9966030122u, 9966030122x, 99660301202, 99660301204, 99660301206

  • Passar modeller
    Porsche Model: 911 Model series: 911 Model type: 4S Type of engine: Turbo Size of motor: 3.6 Brand of engine: M96.70 Type description: 996 Body: Convertible From date: 01-10-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera 4 Size of motor: 3.4 Brand of engine: M96.01 Type description: 996 Body: Coupe From date: 01-09-1997 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera 4 Size of motor: 3.4 Brand of engine: M96.04 Type description: 996 Body: Coupe From date: 01-09-1997 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera 4 Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Convertible From date: 01-10-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera 4 Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Coupe From date: 01-10-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera 4 Type of engine: S Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Convertible From date: 01-06-2002 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera 4 Type of engine: S Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Coupe From date: 01-02-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera Size of motor: 3.4 Brand of engine: M96.01 Type description: 996 Body: Convertible From date: 01-02-1998 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera Size of motor: 3.4 Brand of engine: M96.01 Type description: 996 Body: Coupe From date: 01-09-1997 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera Size of motor: 3.4 Brand of engine: M96.04 Type description: 996 Body: Convertible From date: 01-02-1998 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera Size of motor: 3.4 Brand of engine: M96.04 Type description: 996 Body: Coupe From date: 01-09-1997 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera Type of engine: S Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Convertible From date: 01-06-2002 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Carrera Type of engine: S Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Coupe From date: 01-02-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: GT2 Size of motor: 3.6 Brand of engine: M96.70 Type description: 996 Body: Coupe From date: 01-04-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: GT2 Size of motor: 3.6 Brand of engine: M96.70 Type description: 996 Body: Coupe From date: 01-10-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: S Size of motor: 3.6 Brand of engine: M96.70 Type description: 996 Body: Convertible From date: 01-08-2004 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: S Size of motor: 3.6 Type description: 996 Body: Coupe From date: 01-08-2004 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: S Type of engine: Turbo Size of motor: 3.6 Brand of engine: M96.70 Body: Coupe From date: 01-02-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Model type: Targa Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 From date: 01-12-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Convertible From date: 01-10-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Coupe From date: 01-10-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: 911 Model series: 911 Type of engine: Turbo Size of motor: 3.6 Brand of engine: M96.70 Type description: 996 Body: Convertible From date: 01-10-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
    Porsche Model: Boxster Model series: Boxster Model type: S Size of motor: 3.2 Brand of engine: M96.24 Type description: 986 Body: Convertible From date: 01-01-2004 To date: 01-12-2004 Fuel: Gasoline Approved: Yes
    Porsche Model: Boxster Model series: Boxster Model type: S Size of motor: 3.2 Brand of engine: M96.24 Type description: 986 Body: Convertible From date: 01-07-2002 To date: 01-12-2004 Fuel: Gasoline Approved: Yes
    Porsche Model: Boxster Model series: Boxster Size of motor: 2.7 Brand of engine: M96.22 Type description: 986 Body: Convertible From date: 01-08-1999 To date: 01-07-2002 Fuel: Gasoline Approved: Yes
    Porsche Model: Boxster Model series: Boxster Size of motor: 3.2 Brand of engine: M96.21 Type description: 986 Body: Convertible From date: 01-08-1999 To date: 01-07-2002 Fuel: Gasoline Approved: Yes
    Porsche Model: Boxster Model series: Boxster Type of engine: 24V Size of motor: 2.7 Brand of engine: M96.23 Type description: 986 Body: Convertible From date: 01-07-2002 To date: 01-12-2004 Fuel: Gasoline Approved: Yes
    1 / 6
  • Beskrivelse
    Spænding: 14
    Amp: 120
    Skive dist.: 32.00
    Bredde/holderarms: 14.00
    Monteringsbeslag dist.: 82.00
    Beslagshuls: 10.50
    Bælte. justering beslagshuls pos.: 50
    Bælte. justering beslagshuls 1: M10
    Skive diameter: 53.00
    Riller/skive: 6
    Radius: 92.00
    Radius 2: 96.00
    B+: M8
    Pos. / B+ i min.: 30
    D+ Størrelse: Stik
    Rotation: CW
    Stik nr.: PL61
    Total længde mm: 187.00
    Terminaltype: L-DFM
    Skive: SP/FW
    Regulator type: IR
    Produktoplysninger: BN

    Filer

  • Specifikation
    B+ M8
    Mount. bracket dist. 82.00
    Belt. adj. bracket hole 1 M10
    Belt. adj. brackethole pos. 50
    Plug no. PL61
    Bracket hole 10.50
    Position/B+ in min. 30
    Prod. info BN
    Pulley SP/FW
    Pulley dia. 53.00
    Pulley dist. 32.00
    Radius 92.00
    D+ Size Plug
    Radius 2 96.00
    Regulator type IR
    Rotation CW
    Grooves/pulley 6
    Terminal type L-DFM
    Voltage 14
    Total length 187.00 mm
    Width/holder arm 14.00
    Amp 120
  • Køretøjsmatchning

    • OEM
      F032115835, 1986A00847, 24436554, 0124515072, 0124515073, 9966030122U, 9966030122X, 99660301202, 99660301204, 99660301206

    • Konkurrentreferens
      A0486, CAL10287, DRB6520, LRA02859, 28-4975, 211.316.1202, 485.502.120, 11041N, 11041R, 209414, 209414A, 444240, 9046520, 12044450, 12046520, 0986046520, 0986046523, 0986046527

    • NormaliseratArtNr
      a0486, cal10287, drb6520, f032115835, lra02859, 1986a00847, 11041n, 11041r, 209414, 209414a, 284975, 444240, 9046520, 12044450, 12046520, 24436554, 0124515072, 0124515073, 485502120, 0986046520, 0986046523, 0986046527, 2113161202, 9966030122u, 9966030122x, 99660301202, 99660301204, 99660301206

    • Passar modeller
      Porsche Model: 911 Model series: 911 Model type: 4S Type of engine: Turbo Size of motor: 3.6 Brand of engine: M96.70 Type description: 996 Body: Convertible From date: 01-10-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera 4 Size of motor: 3.4 Brand of engine: M96.01 Type description: 996 Body: Coupe From date: 01-09-1997 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera 4 Size of motor: 3.4 Brand of engine: M96.04 Type description: 996 Body: Coupe From date: 01-09-1997 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera 4 Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Convertible From date: 01-10-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera 4 Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Coupe From date: 01-10-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera 4 Type of engine: S Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Convertible From date: 01-06-2002 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera 4 Type of engine: S Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Coupe From date: 01-02-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera Size of motor: 3.4 Brand of engine: M96.01 Type description: 996 Body: Convertible From date: 01-02-1998 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera Size of motor: 3.4 Brand of engine: M96.01 Type description: 996 Body: Coupe From date: 01-09-1997 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera Size of motor: 3.4 Brand of engine: M96.04 Type description: 996 Body: Convertible From date: 01-02-1998 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera Size of motor: 3.4 Brand of engine: M96.04 Type description: 996 Body: Coupe From date: 01-09-1997 To date: 01-09-2001 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera Type of engine: S Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Convertible From date: 01-06-2002 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Carrera Type of engine: S Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Coupe From date: 01-02-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: GT2 Size of motor: 3.6 Brand of engine: M96.70 Type description: 996 Body: Coupe From date: 01-04-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: GT2 Size of motor: 3.6 Brand of engine: M96.70 Type description: 996 Body: Coupe From date: 01-10-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: S Size of motor: 3.6 Brand of engine: M96.70 Type description: 996 Body: Convertible From date: 01-08-2004 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: S Size of motor: 3.6 Type description: 996 Body: Coupe From date: 01-08-2004 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: S Type of engine: Turbo Size of motor: 3.6 Brand of engine: M96.70 Body: Coupe From date: 01-02-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Model type: Targa Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 From date: 01-12-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Convertible From date: 01-10-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Size of motor: 3.6 Brand of engine: M96.03 Type description: 996 Body: Coupe From date: 01-10-2001 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: 911 Model series: 911 Type of engine: Turbo Size of motor: 3.6 Brand of engine: M96.70 Type description: 996 Body: Convertible From date: 01-10-2003 To date: 01-08-2005 Fuel: Gasoline Approved: Yes
      Porsche Model: Boxster Model series: Boxster Model type: S Size of motor: 3.2 Brand of engine: M96.24 Type description: 986 Body: Convertible From date: 01-01-2004 To date: 01-12-2004 Fuel: Gasoline Approved: Yes
      Porsche Model: Boxster Model series: Boxster Model type: S Size of motor: 3.2 Brand of engine: M96.24 Type description: 986 Body: Convertible From date: 01-07-2002 To date: 01-12-2004 Fuel: Gasoline Approved: Yes
      Porsche Model: Boxster Model series: Boxster Size of motor: 2.7 Brand of engine: M96.22 Type description: 986 Body: Convertible From date: 01-08-1999 To date: 01-07-2002 Fuel: Gasoline Approved: Yes
      Porsche Model: Boxster Model series: Boxster Size of motor: 3.2 Brand of engine: M96.21 Type description: 986 Body: Convertible From date: 01-08-1999 To date: 01-07-2002 Fuel: Gasoline Approved: Yes
      Porsche Model: Boxster Model series: Boxster Type of engine: 24V Size of motor: 2.7 Brand of engine: M96.23 Type description: 986 Body: Convertible From date: 01-07-2002 To date: 01-12-2004 Fuel: Gasoline Approved: Yes
      1 / 6
