HC-Cargo Generator
HC-Cargo Generator
Vare nr.: F032115737

HC-Cargo Generator

Tekniske oplysninger:

Spænding: 14, Amp: 130, Rotation: CW, Monteringsstøtte afstand: 43.00

Beskrivelse

Spænding: 14
Ampere: 130
Drevskive dist.: 42,50
Bredde/beslag arm: 20,00
Fastgørelsesbeslag dist.: 43,00
Beslagshul: 11,00
Bælte justering beslag hul position.: 53
Bælte justering beslag hul 1: 11,00
Drevskive dia.: 53,30
Riller/drevskive: 6
radius: 90,00
radius 2: 84,00
B+: M8
Position/B+ i min.: 58
D+ størrelse: Stik
Rotation: Klokken-halv: CW
Stik nr.: PL133
Samlet længde mm: 188,00
Drevskive: SP
Regulator type: IR
Produktion info: BN

Filer

Specifikation

B+ M8
Mount. bracket dist. 43.00
Belt. adj. bracket hole 1 11.00
Belt. adj. brackethole pos. 53
Plug no. PL133
Bracket hole 11.00
Position/B+ in min. 58
Prod. info BN
Pulley SP
Pulley dia. 53.30
Pulley dist. 42.50
Radius 90.00
D+ Size Plug
Radius 2 84.00
Regulator type IR
Rotation CW
Grooves/pulley 6
Voltage 14
Total length 188.00 mm
Width/holder arm 20.00
Amp 130

  • OEM
    F032115737, TG12C057, 02131-9152, 02131-9153, 02131-9330, 37300-3c120, 37300-3C170, 37300-3C250, 102211-3102, 102211-3240

  • Konkurrentreferens
    A3339, A6354, CAL41119, 255.512.130, 11191, 11191N, 11191R, 12061035

  • NormaliseratArtNr
    a3339, a6354, cal41119, f032115737, tg12c057, 11191, 11191n, 11191r, 373003c120, 373003c170, 373003c250, 12061035, 021319152, 021319153, 021319330, 255512130, 1022113102, 1022113240

  • Passar modeller
    Hyundai Model: Grandeur Model series: Grandeur Size of motor: 3.3 Brand of engine: G6DB From date: 01-04-2005 To date: 01-12-2010 Fuel: Gasoline Approved: Yes
    Hyundai Model: Grandeur Model series: Grandeur Size of motor: 3.3 Brand of engine: G6DB Type description: TG From date: 01-02-2007 To date: 01-12-2011 Fuel: Gasoline Approved: Yes
    Hyundai Model: Grandeur Model series: Grandeur Size of motor: 3.3 Brand of engine: G6DB Type description: TG From date: 01-11-2010 To date: 01-12-2011 Fuel: Gasoline Approved: Yes
    Hyundai Model: ix55 Model series: ix55 Model type: AWD Type of engine: V6 Size of motor: 3.8 Brand of engine: G6DA From date: 01-01-2011 Fuel: Gasoline Approved: Yes
    Hyundai Model: Ix55 Model series: Ix55 Model type: AWD Type of engine: V6 Size of motor: 3.8 From date: 01-01-2007 Fuel: Gasoline Approved: Yes
    Hyundai Model: Santa F Model series: Santa F Model type: 4WD GLS Type of engine: V6 Size of motor: 2.7 Brand of engine: G6EA Body: SUV From date: 01-03-2006 To date: 01-12-2009 Fuel: Gasoline Approved: Yes
    Hyundai Model: Santa F Model series: Santa F Model type: 4x4 Size of motor: 2.7 Brand of engine: G6BA Type description: CM Body: SUV From date: 01-03-2006 To date: 01-12-2012 Fuel: Gasoline Approved: Yes
    Hyundai Model: Santa F Model series: Santa F Model type: Dynamic 4WD Size of motor: 3.3 Brand of engine: G6DB Body: SUV From date: 01-03-2006 To date: 01-12-2012 Fuel: Gasoline Approved: Yes
    Hyundai Model: Santa F Model series: Santa F Model type: GLS Type of engine: V6 Size of motor: 2.7 Brand of engine: G6EA Body: SUV From date: 01-03-2006 To date: 01-12-2009 Fuel: Gasoline Approved: Yes
    Hyundai Model: Santa F Model series: Santa F Size of motor: 2.7 Brand of engine: G6BA Type description: CM Body: SUV From date: 01-03-2006 To date: 01-12-2012 Fuel: Gasoline Approved: Yes
    Hyundai Model: Santa F Model series: Santa F Size of motor: 2.7 Brand of engine: G6EA Type description: CM Body: Box Body / Estate From date: 01-01-2007 To date: 01-12-2008 Fuel: Petrol Approved: Yes
    Hyundai Model: Santa F? Model series: Santa F? Model type: GLS Size of motor: 2.7 Brand of engine: G6EA Type description: CM Body: SUV Van Fuel: Petrol Approved: Yes
    Hyundai Model: Sonata Model series: Sonata Size of motor: 3.3 Brand of engine: G6DB From date: 01-01-2005 To date: 01-12-2010 Fuel: Gasoline Approved: Yes
    Hyundai Model: Sonata Model series: Sonata Size of motor: 3.3 Brand of engine: G6DB From date: 01-01-2008 To date: 01-12-2010 Fuel: Gasoline Approved: Yes
    Hyundai Model: Sonata Model series: Sonata Size of motor: 3.3 Brand of engine: G6DB From date: 01-06-2005 To date: 01-12-2010 Fuel: Gasoline Approved: Yes
    Hyundai Model: Sonata Model series: Sonata Size of motor: 3.3 Brand of engine: G6DB Type description: NF Body: Saloon From date: 01-09-2007 To date: 01-12-2008 Fuel: Petrol Approved: Yes
    Kia Model: Borrego Model series: Borrego Model type: 4WD Size of motor: 3.8 Brand of engine: G6RB Type description: HM Body: SUV Fuel: Petrol Approved: Yes
    Kia Model: Borrego Model series: Borrego Model type: 4WD Size of motor: 3.8 From date: 01-06-2008 Fuel: Gasoline Approved: Yes
    Kia Model: Borrego Model series: Borrego Size of motor: 3.8 Brand of engine: G6RB Type description: HM Body: SUV Fuel: Petrol Approved: Yes
    Kia Model: Sorento Model series: Sorento Model type: 4WD Size of motor: 3.3 Brand of engine: G6DB Type description: JC Body: SUV From date: 01-09-2008 To date: 01-12-2009 Fuel: Petrol Approved: Yes
    Kia Model: Sorento Model series: Sorento Model type: 4x4 Size of motor: 3.8 Type description: JC Body: SUV From date: 01-09-2006 Fuel: Gasoline Approved: Yes
    Kia Model: Sorento Model series: Sorento Type of engine: V6 Size of motor: 3.3 Brand of engine: G6DB Type description: JC Body: SUV From date: 01-02-2007 Fuel: Gasoline Approved: Yes
