HC-Cargo Generator
HC-Cargo Generator
Vare nr.: F032116125

HC-Cargo Generator

Tekniske oplysninger:

Spænding: 14, Amp: 120, Rotation: P, Monteringsbeslag afstand: 50,00

Beskrivelse

HC-Cargo Generator 14V - 120A, 5gr

Spænding: 14
Ampere: 120
Remskive dist.: 17.00
Bredde/holderarm: 24.00
Monteringsbøjningens dist.: 50.00
Bøjningens hul: 8.50
Bøjningens hul 2: 10.50
Bæltespændingsbøjningens hul 1: 8.50
Bæltespændingsbøjningens hul 2: 10.50
Remskive dia.: 54.00
Riller/remskive: 5
B+: M8
Position/B+ i min.: 10
Rotation: CW
Stik nr.: PL174
Total længde mm: 197.00
Terminaltype: COM
Kommunikation: LIN
Remskive: SP/FW
Spændingsregulator type: IR
Produktinfo: BN
Bemærkninger: Denne Generator har en COM-terminal på spændingsregulatoren. Det anbefales at bruge OEM-nummeret til at kontrollere egnethed, inden der bestilles.

Filer

Specifikation

B+ M8
Communication LIN
Mount. bracket dist. 50.00
Belt. adj. bracket hole 1 8.50
Belt. adj. bracket hole 2 10.50
Plug no. PL174
Bracket hole 8.50
Bracket hole 2 10.50
Position/B+ in min. 10
Prod. info BN
Pulley SP/FW
Pulley dia. 54.00
Pulley dist. 17.00
Regulator type IR
Remarks This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.
Rotation CW
Grooves/pulley 5
Terminal type COM
Voltage 14
Total length 197.00 mm
Width/holder arm 24.00
Amp 120

  • OEM
    F032116125, 1986A00607, 101210-1660, 101210-1670, 101210-1840, 104211-4820, 116125, 51874104, 51874105, 51929095, 52137908

  • Konkurrentreferens
    A6130, A6130(DENSO), A6130S, CAL40372, DAN1078, DRA1318, LRA03659, 28-6799, 505.574.120, 210948, 210948A, 553583RI, 12090749, 32561010, 0986084710

  • Bilmärken
    Alfa Romeo, Fiat, Jeep - AMC - Eagle

  • NormaliseratArtNr
    a6130, a6130denso, a6130s, cal40372, dan1078, dra1318, f032116125, lra03659, 1986a00607, 116125, 210948, 210948a, 286799, 553583ri, 12090749, 32561010, 51874104, 51874105, 51929095, 52137908, 505574120, 0986084710, 1012101660, 1012101670, 1012101840, 1042114820

  • Passar modeller
    Alfa Romeo Model: Giulietta Model series: Giulietta Size of motor: 1.4 Brand of engine: 198A4.000 Type description: 940_ Body: Box From date: 01-04-2011 To date: 01-02-2016 Fuel: Gasoline Approved: Yes
    Alfa Romeo Model: Giulietta Model series: Giulietta Size of motor: 1.4 Brand of engine: 940A2.000 Type description: 940_ Body: Box From date: 01-04-2011 Fuel: Gasoline Approved: Yes
    Alfa Romeo Series: GIULIETTA Skåp/halvk Model: 1.4 Engine volume: 1.4 Engine type: 198 A4.000 Year: 04.11-02.16
    Alfa Romeo Series: GIULIETTA Skåp/halvk Model: 1.4 Engine volume: 1.4 Engine type: 940 A2.000 Year: 04.11-12.20
    Fiat Model: 500 C Model series: 500 C Size of motor: 0.9 Brand of engine: 312A6.000 Type description: 312_ Body: Convertible From date: 01-12-2013 Fuel: Gasoline Approved: Yes
    Fiat Model: 500 Model series: 500 Size of motor: 0.9 Brand of engine: 312A2.000 Type description: 150 Body: Hatchback From date: 01-07-2010 Fuel: Gasoline Approved: Yes
    Fiat Model: 500 Model series: 500L Model type: CNG Size of motor: 0.9 Brand of engine: 312A2.000 Body: Hatchback From date: 01-03-2013 Fuel: Gasoline/gas Approved: Yes
    Fiat Model: Tipo Model series: Tipo Type of engine: LPG Size of motor: 1.4 Brand of engine: 940B7.000 Type description: 356_ Body: Estate From date: 01-05-2016 Fuel: Gasoline Approved: Yes Manufacture type: Estate
    Fiat Model: Tipo Model series: Tipo Type of engine: LPG Size of motor: 1.4 Brand of engine: 940B7.000 Type description: 356_ Body: Hatchback From date: 01-05-2016 Fuel: Gasoline Approved: Yes
    Fiat Series: 500 C (312_) Model: 0.9 (312AXP1A) Engine volume: 0,9 Engine type: 312 A6.000 Year: 12.13-
    Fiat Series: 500 Model: 0.9 Engine volume: 0.9 Engine type: 312.A2.000 Year: 07.10-
    Fiat Series: 500L Model: 0.9 Natural Power Engine volume: 0.9 Engine type: 312 A2.000 Year: 03.13-
    Fiat Series: TIPO Halvkombi Model: 1.4 LPG Engine volume: 1.4 Engine type: 940 B7.000 Year: 05.16-10.20
    Fiat Series: TIPO Kombi Model: 1.4 LPG Engine volume: 1.4 Engine type: 940 B7.000 Year: 05.16-10.20
    Jeep - AMC - Eagle Series: RENEGADE SUV Model: 1.4 Engine volume: 1.4 Engine type: 552 63 624 Year: 01.16-
    Jeep - AMC - Eagle Series: RENEGADE VAN Model: 1.4 4x4 Engine volume: 1.4 Engine type: 552 63 623 Year: 07.14-
    Jeep - AMC - Eagle Series: RENEGADE VAN Model: 1.4 Engine volume: 1.4 Engine type: 552 63 624 Year: 07.14-
    Jeep Model: Renegade Model series: Renegade Model type: 4X4 Size of motor: 1.4 Brand of engine: 55263623 Type description: BU, B1 Body: Box Body / Estate From date: 01-07-2014 Fuel: Petrol Approved: Yes
    Jeep Model: Renegade Model series: Renegade Size of motor: 1.4 Brand of engine: 55263624 Type description: BU, B1 Body: Box Body / Estate From date: 01-07-2014 Fuel: Petrol Approved: Yes
    Jeep Model: Renegade Model series: Renegade Size of motor: 1.4 Brand of engine: 55263624 Type description: BU, B1 Body: Closed Off-Road Vehicle From date: 01-01-2016 Fuel: Gasoline Approved: Yes
    1 / 4
  • Beskrivelse
    HC-Cargo Generator 14V - 120A, 5gr

    Spænding: 14
    Ampere: 120
    Remskive dist.: 17.00
    Bredde/holderarm: 24.00
    Monteringsbøjningens dist.: 50.00
    Bøjningens hul: 8.50
    Bøjningens hul 2: 10.50
    Bæltespændingsbøjningens hul 1: 8.50
    Bæltespændingsbøjningens hul 2: 10.50
    Remskive dia.: 54.00
    Riller/remskive: 5
    B+: M8
    Position/B+ i min.: 10
    Rotation: CW
    Stik nr.: PL174
    Total længde mm: 197.00
    Terminaltype: COM
    Kommunikation: LIN
    Remskive: SP/FW
    Spændingsregulator type: IR
    Produktinfo: BN
    Bemærkninger: Denne Generator har en COM-terminal på spændingsregulatoren. Det anbefales at bruge OEM-nummeret til at kontrollere egnethed, inden der bestilles.

    Filer

  • Specifikation
    B+ M8
    Communication LIN
    Mount. bracket dist. 50.00
    Belt. adj. bracket hole 1 8.50
    Belt. adj. bracket hole 2 10.50
    Plug no. PL174
    Bracket hole 8.50
    Bracket hole 2 10.50
    Position/B+ in min. 10
    Prod. info BN
    Pulley SP/FW
    Pulley dia. 54.00
    Pulley dist. 17.00
    Regulator type IR
    Remarks This Alternator has a COM terminal on the regulator. It is recommended that the OEM number is used to check suitability before ordering.
    Rotation CW
    Grooves/pulley 5
    Terminal type COM
    Voltage 14
    Total length 197.00 mm
    Width/holder arm 24.00
    Amp 120
  • Køretøjsmatchning

    • OEM
      F032116125, 1986A00607, 101210-1660, 101210-1670, 101210-1840, 104211-4820, 116125, 51874104, 51874105, 51929095, 52137908

    • Konkurrentreferens
      A6130, A6130(DENSO), A6130S, CAL40372, DAN1078, DRA1318, LRA03659, 28-6799, 505.574.120, 210948, 210948A, 553583RI, 12090749, 32561010, 0986084710

    • Bilmärken
      Alfa Romeo, Fiat, Jeep - AMC - Eagle

    • NormaliseratArtNr
      a6130, a6130denso, a6130s, cal40372, dan1078, dra1318, f032116125, lra03659, 1986a00607, 116125, 210948, 210948a, 286799, 553583ri, 12090749, 32561010, 51874104, 51874105, 51929095, 52137908, 505574120, 0986084710, 1012101660, 1012101670, 1012101840, 1042114820

    • Passar modeller
      Alfa Romeo Model: Giulietta Model series: Giulietta Size of motor: 1.4 Brand of engine: 198A4.000 Type description: 940_ Body: Box From date: 01-04-2011 To date: 01-02-2016 Fuel: Gasoline Approved: Yes
      Alfa Romeo Model: Giulietta Model series: Giulietta Size of motor: 1.4 Brand of engine: 940A2.000 Type description: 940_ Body: Box From date: 01-04-2011 Fuel: Gasoline Approved: Yes
      Alfa Romeo Series: GIULIETTA Skåp/halvk Model: 1.4 Engine volume: 1.4 Engine type: 198 A4.000 Year: 04.11-02.16
      Alfa Romeo Series: GIULIETTA Skåp/halvk Model: 1.4 Engine volume: 1.4 Engine type: 940 A2.000 Year: 04.11-12.20
      Fiat Model: 500 C Model series: 500 C Size of motor: 0.9 Brand of engine: 312A6.000 Type description: 312_ Body: Convertible From date: 01-12-2013 Fuel: Gasoline Approved: Yes
      Fiat Model: 500 Model series: 500 Size of motor: 0.9 Brand of engine: 312A2.000 Type description: 150 Body: Hatchback From date: 01-07-2010 Fuel: Gasoline Approved: Yes
      Fiat Model: 500 Model series: 500L Model type: CNG Size of motor: 0.9 Brand of engine: 312A2.000 Body: Hatchback From date: 01-03-2013 Fuel: Gasoline/gas Approved: Yes
      Fiat Model: Tipo Model series: Tipo Type of engine: LPG Size of motor: 1.4 Brand of engine: 940B7.000 Type description: 356_ Body: Estate From date: 01-05-2016 Fuel: Gasoline Approved: Yes Manufacture type: Estate
      Fiat Model: Tipo Model series: Tipo Type of engine: LPG Size of motor: 1.4 Brand of engine: 940B7.000 Type description: 356_ Body: Hatchback From date: 01-05-2016 Fuel: Gasoline Approved: Yes
      Fiat Series: 500 C (312_) Model: 0.9 (312AXP1A) Engine volume: 0,9 Engine type: 312 A6.000 Year: 12.13-
      Fiat Series: 500 Model: 0.9 Engine volume: 0.9 Engine type: 312.A2.000 Year: 07.10-
      Fiat Series: 500L Model: 0.9 Natural Power Engine volume: 0.9 Engine type: 312 A2.000 Year: 03.13-
      Fiat Series: TIPO Halvkombi Model: 1.4 LPG Engine volume: 1.4 Engine type: 940 B7.000 Year: 05.16-10.20
      Fiat Series: TIPO Kombi Model: 1.4 LPG Engine volume: 1.4 Engine type: 940 B7.000 Year: 05.16-10.20
      Jeep - AMC - Eagle Series: RENEGADE SUV Model: 1.4 Engine volume: 1.4 Engine type: 552 63 624 Year: 01.16-
      Jeep - AMC - Eagle Series: RENEGADE VAN Model: 1.4 4x4 Engine volume: 1.4 Engine type: 552 63 623 Year: 07.14-
      Jeep - AMC - Eagle Series: RENEGADE VAN Model: 1.4 Engine volume: 1.4 Engine type: 552 63 624 Year: 07.14-
      Jeep Model: Renegade Model series: Renegade Model type: 4X4 Size of motor: 1.4 Brand of engine: 55263623 Type description: BU, B1 Body: Box Body / Estate From date: 01-07-2014 Fuel: Petrol Approved: Yes
      Jeep Model: Renegade Model series: Renegade Size of motor: 1.4 Brand of engine: 55263624 Type description: BU, B1 Body: Box Body / Estate From date: 01-07-2014 Fuel: Petrol Approved: Yes
      Jeep Model: Renegade Model series: Renegade Size of motor: 1.4 Brand of engine: 55263624 Type description: BU, B1 Body: Closed Off-Road Vehicle From date: 01-01-2016 Fuel: Gasoline Approved: Yes
