HC-Cargo Startmotor
HC-Cargo Startmotor
Vare nr.: F032110417

HC-Cargo Startmotor

Tekniske oplysninger:

Spænding: 12, kW: 1.3, No./tænder: 9, Rotation: CW

Beskrivelse

Spænding: 12
kW: 1.3
Montering. flange: 89,00
Drevafstand: 17,50
Montering. hul 2 mm: 10,50
Montering. hul 1 mm: 10,50
Afstand/tilbagestilling: 138,00
Afstand/forreste: 53,00
Nr./tænder: 9
B+: M8
Trådlængde mm: 15,00
Positions/50: 60
Terminal 50: 6,30
Kogetype: GR
Afstand mm: 131,50
Rotation: UØ
Total længde mm: 194,00
Drevetype: Stål
Prod. info: BN
Vandtæt: Nej
Oliesikret: Nej
Nr./monteringshuller: 2 (0)

Filer

Specifikation

B+ M8
No./teeth 9
Mount. flange 89.00
Oil sealed No
No./mount. holes 2 (0)
Position/50 60
Prod. info BN
Rotation CW
Dist./back 138.00
Dist./front 53.00
Drive dist. 17.50
Drive type Steel
Gear type GR
kW 1.3
Terminal 50 6.30
Voltage 12
Total length 194.00 mm
Waterproof No
Dist. 131.50 mm
Thread length 15.00 mm
Mount. hole 2 10.50 mm
Mount. hole 1 10.50 mm

  • OEM
    am880978, F032110417, js729, M809215, S114-231B, s114-235, s114-235a, S114-235B, s114-625, 119865-77010, 119865-77011, 121450-77010, 124395-77010

  • Konkurrentreferens
    ays-900, CST20136, drs3259, LRS01124, PBNS3025, s-8551, shi0141, sj-00203r, SND0413, STR23004, 8ea730269-001, 25-1061, 91-25-1131, 682.004.112, 4252, 18207, 18426N, 20729, 33516, 106172, 220823, 220823A, 8080016, 0986016081

  • NormaliseratArtNr
    am880978, ays900, cst20136, drs3259, f032110417, js729, lrs01124, m809215, pbns3025, s114231b, s114235, s114235a, s114235b, s114625, s8551, shi0141, sj00203r, snd0413, str23004, 8ea730269001, 4252, 18207, 18426n, 20729, 33516, 106172, 220823, 220823a, 251061, 8080016, 91251131, 682004112, 0986016081, 11986577010, 11986577011, 12145077010, 12439577010

  • Passar modeller
    Yanmar Model: Engine Model series: Various Models Brand of engine: 3T72 Approved: Yes
    Yanmar Model: Engine Model series: Various Models Brand of engine: 3TNA72 Approved: Yes
    Yanmar Model: Engine Model series: Various Models Brand of engine: 3TNA75 Approved: Yes
  • Beskrivelse
    Spænding: 12
    kW: 1.3
    Montering. flange: 89,00
    Drevafstand: 17,50
    Montering. hul 2 mm: 10,50
    Montering. hul 1 mm: 10,50
    Afstand/tilbagestilling: 138,00
    Afstand/forreste: 53,00
    Nr./tænder: 9
    B+: M8
    Trådlængde mm: 15,00
    Positions/50: 60
    Terminal 50: 6,30
    Kogetype: GR
    Afstand mm: 131,50
    Rotation: UØ
    Total længde mm: 194,00
    Drevetype: Stål
    Prod. info: BN
    Vandtæt: Nej
    Oliesikret: Nej
    Nr./monteringshuller: 2 (0)

    Filer

  • Specifikation
    B+ M8
    No./teeth 9
    Mount. flange 89.00
    Oil sealed No
    No./mount. holes 2 (0)
    Position/50 60
    Prod. info BN
    Rotation CW
    Dist./back 138.00
    Dist./front 53.00
    Drive dist. 17.50
    Drive type Steel
    Gear type GR
    kW 1.3
    Terminal 50 6.30
    Voltage 12
    Total length 194.00 mm
    Waterproof No
    Dist. 131.50 mm
    Thread length 15.00 mm
    Mount. hole 2 10.50 mm
    Mount. hole 1 10.50 mm
  • Køretøjsmatchning

    • OEM
      am880978, F032110417, js729, M809215, S114-231B, s114-235, s114-235a, S114-235B, s114-625, 119865-77010, 119865-77011, 121450-77010, 124395-77010

    • Konkurrentreferens
      ays-900, CST20136, drs3259, LRS01124, PBNS3025, s-8551, shi0141, sj-00203r, SND0413, STR23004, 8ea730269-001, 25-1061, 91-25-1131, 682.004.112, 4252, 18207, 18426N, 20729, 33516, 106172, 220823, 220823A, 8080016, 0986016081

    • NormaliseratArtNr
      am880978, ays900, cst20136, drs3259, f032110417, js729, lrs01124, m809215, pbns3025, s114231b, s114235, s114235a, s114235b, s114625, s8551, shi0141, sj00203r, snd0413, str23004, 8ea730269001, 4252, 18207, 18426n, 20729, 33516, 106172, 220823, 220823a, 251061, 8080016, 91251131, 682004112, 0986016081, 11986577010, 11986577011, 12145077010, 12439577010

    • Passar modeller
      Yanmar Model: Engine Model series: Various Models Brand of engine: 3T72 Approved: Yes
      Yanmar Model: Engine Model series: Various Models Brand of engine: 3TNA72 Approved: Yes
      Yanmar Model: Engine Model series: Various Models Brand of engine: 3TNA75 Approved: Yes
