HC-Cargo Startmotor
HC-Cargo Startmotor
Vare nr.: F032116003

HC-Cargo Startmotor

Tekniske oplysninger:

Spænding: 12, kW: 1.2, No./tænder: 9, Rotation: CW

Beskrivelse

Spændingsføler: 12
kW: 1.2
Monteringsflanger: 74.00
Drevafstand: 24.00
Monteringshul 1 mm: 11.00
Afstand/bag: 126.00
Afstand/frem: 56.50
Antal/tenner: 9
B+: M8
Position/50: 38
Terminal 50: Stik
Geartype: GR
Afstand mm: 138.50
Rotation: med uret
Total længde mm: 182.50
Antal/monteringshuller: 2 (1)

Filer

Specifikation

B+ M8
No./teeth 9
Mount. flange 74.00
No./mount. holes 2 (1)
Position/50 38
Rotation CW
Dist./back 126.00
Dist./front 56.50
Drive dist. 24.00
Gear type GR
kW 1.2
Terminal 50 Plug
Voltage 12
Total length 182.50 mm
Dist. 138.50 mm
Mount. hole 1 11.00 mm

  • OEM
    F032116003, 1986S01000, 28100-0Y090, 28100-0Y091, 28100-0Y100, 28100-0Y101, 28100-47170, 28100-47171, 28100-47180, 428000-7900, 428000-7902, 428000-7904, 428000-7905, 428000-7910, 428000-7911, 428000-7912, 428000-7913, 428000-7914, 428000-7915, 428000-8430, 428000-8431, 428000-8432, 428000-8433, 428000-8434, 428000-8435, 428000-8440, 428000-8441, 428000-8443, 428000-8444, 428000-8445

  • Konkurrentreferens
    CST40299, DSN1009, S6245(DENSO), S6245S, S6295S, 25-5091, 25-5098, 190.925.092, 335.249.092, 335.250.092, 255260, 11040889, 0986026460

  • NormaliseratArtNr
    cst40299, dsn1009, f032116003, s6245denso, s6245s, s6295s, 1986s01000, 255091, 255098, 255260, 281000y090, 281000y091, 281000y100, 281000y101, 11040889, 190925092, 335249092, 335250092, 0986026460, 2810047170, 2810047171, 2810047180, 4280007900, 4280007902, 4280007904, 4280007905, 4280007910, 4280007911, 4280007912, 4280007913, 4280007914, 4280007915, 4280008430, 4280008431, 4280008432, 4280008433, 4280008434, 4280008435, 4280008440, 4280008441, 4280008443, 4280008444, 4280008445

  • Passar modeller
    Toyota Model: Auris Model series: Auris Size of motor: 1.3 Brand of engine: 1NR-FE Type description: NZE18_, ZRE18_ Body: Hatchback From date: 01-10-2012 To date: 01-12-2018 Fuel: Gasoline Approved: Yes
    Toyota Model: Auris Model series: Auris Touring Sports Size of motor: 1.3 Brand of engine: 1NR-FE Body: Estate From date: 01-07-2013 To date: 01-12-2018 Fuel: Gasoline Approved: Yes Manufacture type: Touring Sp
    Toyota Model: Corolla Model series: Corolla Size of motor: 1.3 Brand of engine: 1NR-FE Type description: NRE18_, ZRE18_, NDE18_ From date: 01-06-2013 To date: 01-12-2018 Fuel: Gasoline Approved: Yes
    Toyota Model: Vitz Model series: Vitz Size of motor: 1.5 Brand of engine: 2NR-FKE Type description: _P13_ Body: Hatchback From date: 01-03-2017 Fuel: Gasoline Approved: Yes
    Toyota Model: Yaris Model series: Yaris Size of motor: 1.3 Brand of engine: 1NR-FE Type description: _P13_ Body: Hatchback From date: 01-09-2011 Fuel: Gasoline Approved: Yes
    Toyota Model: Yaris Model series: Yaris Size of motor: 1.3 Brand of engine: 1NR-FE Type description: _P13_ Body: Hatchback From date: 01-12-2010 Fuel: Gasoline Approved: Yes
    Toyota Model: Yaris Model series: Yaris Size of motor: 1.3 Brand of engine: 1NR-FKE Type description: _P13_ Body: Hatchback From date: 01-09-2011 Fuel: Gasoline Approved: Yes
    1 / 2
  • Beskrivelse
    Spændingsføler: 12
    kW: 1.2
    Monteringsflanger: 74.00
    Drevafstand: 24.00
    Monteringshul 1 mm: 11.00
    Afstand/bag: 126.00
    Afstand/frem: 56.50
    Antal/tenner: 9
    B+: M8
    Position/50: 38
    Terminal 50: Stik
    Geartype: GR
    Afstand mm: 138.50
    Rotation: med uret
    Total længde mm: 182.50
    Antal/monteringshuller: 2 (1)

    Filer

  • Specifikation
    B+ M8
    No./teeth 9
    Mount. flange 74.00
    No./mount. holes 2 (1)
    Position/50 38
    Rotation CW
    Dist./back 126.00
    Dist./front 56.50
    Drive dist. 24.00
    Gear type GR
    kW 1.2
    Terminal 50 Plug
    Voltage 12
    Total length 182.50 mm
    Dist. 138.50 mm
    Mount. hole 1 11.00 mm
  • Køretøjsmatchning

    • OEM
      F032116003, 1986S01000, 28100-0Y090, 28100-0Y091, 28100-0Y100, 28100-0Y101, 28100-47170, 28100-47171, 28100-47180, 428000-7900, 428000-7902, 428000-7904, 428000-7905, 428000-7910, 428000-7911, 428000-7912, 428000-7913, 428000-7914, 428000-7915, 428000-8430, 428000-8431, 428000-8432, 428000-8433, 428000-8434, 428000-8435, 428000-8440, 428000-8441, 428000-8443, 428000-8444, 428000-8445

    • Konkurrentreferens
      CST40299, DSN1009, S6245(DENSO), S6245S, S6295S, 25-5091, 25-5098, 190.925.092, 335.249.092, 335.250.092, 255260, 11040889, 0986026460

    • NormaliseratArtNr
      cst40299, dsn1009, f032116003, s6245denso, s6245s, s6295s, 1986s01000, 255091, 255098, 255260, 281000y090, 281000y091, 281000y100, 281000y101, 11040889, 190925092, 335249092, 335250092, 0986026460, 2810047170, 2810047171, 2810047180, 4280007900, 4280007902, 4280007904, 4280007905, 4280007910, 4280007911, 4280007912, 4280007913, 4280007914, 4280007915, 4280008430, 4280008431, 4280008432, 4280008433, 4280008434, 4280008435, 4280008440, 4280008441, 4280008443, 4280008444, 4280008445

    • Passar modeller
      Toyota Model: Auris Model series: Auris Size of motor: 1.3 Brand of engine: 1NR-FE Type description: NZE18_, ZRE18_ Body: Hatchback From date: 01-10-2012 To date: 01-12-2018 Fuel: Gasoline Approved: Yes
      Toyota Model: Auris Model series: Auris Touring Sports Size of motor: 1.3 Brand of engine: 1NR-FE Body: Estate From date: 01-07-2013 To date: 01-12-2018 Fuel: Gasoline Approved: Yes Manufacture type: Touring Sp
      Toyota Model: Corolla Model series: Corolla Size of motor: 1.3 Brand of engine: 1NR-FE Type description: NRE18_, ZRE18_, NDE18_ From date: 01-06-2013 To date: 01-12-2018 Fuel: Gasoline Approved: Yes
      Toyota Model: Vitz Model series: Vitz Size of motor: 1.5 Brand of engine: 2NR-FKE Type description: _P13_ Body: Hatchback From date: 01-03-2017 Fuel: Gasoline Approved: Yes
      Toyota Model: Yaris Model series: Yaris Size of motor: 1.3 Brand of engine: 1NR-FE Type description: _P13_ Body: Hatchback From date: 01-09-2011 Fuel: Gasoline Approved: Yes
      Toyota Model: Yaris Model series: Yaris Size of motor: 1.3 Brand of engine: 1NR-FE Type description: _P13_ Body: Hatchback From date: 01-12-2010 Fuel: Gasoline Approved: Yes
      Toyota Model: Yaris Model series: Yaris Size of motor: 1.3 Brand of engine: 1NR-FKE Type description: _P13_ Body: Hatchback From date: 01-09-2011 Fuel: Gasoline Approved: Yes
