HC-Cargo Startmotor
HC-Cargo Startmotor
Vare nr.: F032112670

HC-Cargo Startmotor

Tekniske oplysninger:

Spænding: 24, kW: 4.0, No./tænder: 10, Rotation: CW

Beskrivelse

Daf/Hanomag/Perkins Startm.24V 24V - 4.0kW, 10k. Ikke olietæt. A - 89mm, B - 29mm 2008-01-15 Hvis denne startmotor (4.0kW) monteres i stedet for CAV-startmotor (7.8kW), er det på KUNDENS EGEN RISK, og GARANTIEN GÆLDER IKKE!! For Yourex produkt ordre 91-441-1377

Spænding: 24
kW: 4.0
Monteringsflange: 89,00
Drevafstand: 28,50
Monteringshul 3 mm: 11,00
Monteringshul 2 mm: 11,00
Monteringshul 1 mm: 11,00
Afstand/bag: 252,00
Afstand/forside: 76,00
Antal/tænder: 10
B+: M10
Position/50: 45
Terminal 50: M4
Geartype: DD
Afstand 2: 127,00
Afstand 3: 90,00
Afstand mm: 90,00
Rotation: CW
Total længde mm: 341,00
Drevetype: Stål
Produktinfo: BN
Vandtæt: Nej
Olieskyllet: Nej
Antal/montageskruer: 3 (0)

Filer

Specifikation

B+ M10
No./teeth 10
Mount. flange 89.00
Oil sealed No
No./mount. holes 3 (0)
Position/50 45
Prod. info BN
Dist. 2 127.00
Dist. 3 90.00
Rotation CW
Dist./back 252.00
Dist./front 76.00
Drive dist. 28.50
Drive type Steel
Gear type DD
kW 4.0
Terminal 50 M4
Voltage 24
Total length 341.00 mm
Waterproof No
Dist. 90.00 mm
Mount. hole 3 11.00 mm
Mount. hole 2 11.00 mm
Mount. hole 1 11.00 mm

  • OEM
    AZJ 3351, AZJ3351, F005510, F032112670, OR1903, PF54924, 0001 368 026, 0001 368 040, 0001 368 051, 11.130.993, 0986 013 770, 0986 013 771, 0993, 2873 K063, 2873K063, 3872D304, 27309, 27309a, 27309e, 27311, 27311a, 27311e, 27311h, 27315, 27315a, 27315b, 27315e, 0001368026, 0001368040, 0001368051, 0001368065, 2873306, 2873347R, 3091293M91, 3091293M92, 8091293M91, 20244940, 5000383929, 5000683929

  • Konkurrentreferens
    CST10668, drs3770, IS0993, LRS01845, MS369, S0284, sbo0077, sr913x, STR25018, ts-6072, 2-2299-BO, 45-1185, 88-13.770, 91-15-7078, 260-67204, 601.003.103, 646.006.104, 701.506.103, 8714, 17654, 18254, 18254N, 33795, 254191, 11013770, 943252252, 0986013770, 0986013771

  • Bilmärken
    Daf, FMG, Gremo, Hanomag, Perkins Engines, Ponsse, Volvo BM / Construction Equipment

  • NormaliseratArtNr
    azj3351, cst10668, drs3770, f005510, f032112670, is0993, lrs01845, ms369, or1903, pf54924, s0284, sbo0077, sr913x, str25018, ts6072, 0993, 2873k063, 3872d304, 8714, 17654, 18254, 18254n, 22299bo, 27309, 27309a, 27309e, 27311, 27311a, 27311e, 27311h, 27315, 27315a, 27315b, 27315e, 33795, 254191, 451185, 0001368026, 0001368040, 0001368051, 0001368065, 2873306, 2873347r, 3091293m91, 3091293m92, 8091293m91, 8813770, 11013770, 11130993, 20244940, 26067204, 91157078, 601003103, 646006104, 701506103, 943252252, 0986013770, 0986013771, 5000383929, 5000683929

  • Passar modeller
    Caterpillar Series: Excavators Model: 205 Engine type: Perkins 4.236 Year: 01.84-12.90
    Caterpillar Series: Excavators Model: 206, 212 Engine type: Perkins 4.236 Year: 01.84-12.90
    Caterpillar Series: Excavators Model: 211 Engine type: Perkins 4.236 Year: 01.84-12.89
    Daf - Trucks Series: F 1400 Model: FA 1400 DF Engine volume: 6.2 Engine type: DF 615 Year: 01.70-11.81
    FMG Series: Skogsmaskin Model: 910.4 Engine type: Perkins 1000.4
    Gremo Series: Skogsmaskin Model: 950, HPV Engine type: Perkins 1000.6
    Hanomag Model: 20 Series Model series: 22C Size of motor: 4.1 From date: 01-02-1980 Fuel: Diesel Approved: Yes
    Hanomag Model: 30 Series Model series: 33C Size of motor: 5.8 Brand of engine: A6.354.4 From date: 01-07-1980 Fuel: Diesel Approved: Yes
    Hanomag Series: 20-Serie Model: 22 C Engine volume: 4.1 Engine type: Perkins-4.248 Year: 02.80-
    Hanomag Series: 30-Serie Model: 33 C Engine volume: 5.8 Engine type: Perkins-A 6.354.4 Year: 07.80-
    Huddig Model: 760 Engine type: Perkins 1004-4T
    Komatsu Series: Grävmaskin Model: 12HT-1, 15HT-3 Engine type: Perkins Year: 01.88-
    Ösa Series: Skogsmaskin Model: 250 Engine type: Perkins
    Perkins Engines Model: 6.354.4 24V Engine volume: 5.8 Year: 07.87-12.89
    Perkins Model: 6 Model series: 6-354 From date: 01-01-1980 Fuel: Diesel Approved: Yes
    Perkins Model: Various Models Model series: Various Models Fuel: Diesel Approved: Yes
    Ponsse Series: Skogsmaskin Model: HS 10, 15 Engine type: Perkins 1000.6
    Ponsse Series: Skogsmaskin Model: S 10, 15 Engine type: Perkins 1000.6
    Timberjack Series: Skogsmaskin Engine type: 6-cyl Perkins
    1 / 4
  • Beskrivelse
    Daf/Hanomag/Perkins Startm.24V 24V - 4.0kW, 10k. Ikke olietæt. A - 89mm, B - 29mm 2008-01-15 Hvis denne startmotor (4.0kW) monteres i stedet for CAV-startmotor (7.8kW), er det på KUNDENS EGEN RISK, og GARANTIEN GÆLDER IKKE!! For Yourex produkt ordre 91-441-1377

    Spænding: 24
    kW: 4.0
    Monteringsflange: 89,00
    Drevafstand: 28,50
    Monteringshul 3 mm: 11,00
    Monteringshul 2 mm: 11,00
    Monteringshul 1 mm: 11,00
    Afstand/bag: 252,00
    Afstand/forside: 76,00
    Antal/tænder: 10
    B+: M10
    Position/50: 45
    Terminal 50: M4
    Geartype: DD
    Afstand 2: 127,00
    Afstand 3: 90,00
    Afstand mm: 90,00
    Rotation: CW
    Total længde mm: 341,00
    Drevetype: Stål
    Produktinfo: BN
    Vandtæt: Nej
    Olieskyllet: Nej
    Antal/montageskruer: 3 (0)

    Filer

  • Specifikation
    B+ M10
    No./teeth 10
    Mount. flange 89.00
    Oil sealed No
    No./mount. holes 3 (0)
    Position/50 45
    Prod. info BN
    Dist. 2 127.00
    Dist. 3 90.00
    Rotation CW
    Dist./back 252.00
    Dist./front 76.00
    Drive dist. 28.50
    Drive type Steel
    Gear type DD
    kW 4.0
    Terminal 50 M4
    Voltage 24
    Total length 341.00 mm
    Waterproof No
    Dist. 90.00 mm
    Mount. hole 3 11.00 mm
    Mount. hole 2 11.00 mm
    Mount. hole 1 11.00 mm
  • Køretøjsmatchning

    • OEM
      AZJ 3351, AZJ3351, F005510, F032112670, OR1903, PF54924, 0001 368 026, 0001 368 040, 0001 368 051, 11.130.993, 0986 013 770, 0986 013 771, 0993, 2873 K063, 2873K063, 3872D304, 27309, 27309a, 27309e, 27311, 27311a, 27311e, 27311h, 27315, 27315a, 27315b, 27315e, 0001368026, 0001368040, 0001368051, 0001368065, 2873306, 2873347R, 3091293M91, 3091293M92, 8091293M91, 20244940, 5000383929, 5000683929

    • Konkurrentreferens
      CST10668, drs3770, IS0993, LRS01845, MS369, S0284, sbo0077, sr913x, STR25018, ts-6072, 2-2299-BO, 45-1185, 88-13.770, 91-15-7078, 260-67204, 601.003.103, 646.006.104, 701.506.103, 8714, 17654, 18254, 18254N, 33795, 254191, 11013770, 943252252, 0986013770, 0986013771

    • Bilmärken
      Daf, FMG, Gremo, Hanomag, Perkins Engines, Ponsse, Volvo BM / Construction Equipment

    • NormaliseratArtNr
      azj3351, cst10668, drs3770, f005510, f032112670, is0993, lrs01845, ms369, or1903, pf54924, s0284, sbo0077, sr913x, str25018, ts6072, 0993, 2873k063, 3872d304, 8714, 17654, 18254, 18254n, 22299bo, 27309, 27309a, 27309e, 27311, 27311a, 27311e, 27311h, 27315, 27315a, 27315b, 27315e, 33795, 254191, 451185, 0001368026, 0001368040, 0001368051, 0001368065, 2873306, 2873347r, 3091293m91, 3091293m92, 8091293m91, 8813770, 11013770, 11130993, 20244940, 26067204, 91157078, 601003103, 646006104, 701506103, 943252252, 0986013770, 0986013771, 5000383929, 5000683929

    • Passar modeller
      Caterpillar Series: Excavators Model: 205 Engine type: Perkins 4.236 Year: 01.84-12.90
      Caterpillar Series: Excavators Model: 206, 212 Engine type: Perkins 4.236 Year: 01.84-12.90
      Caterpillar Series: Excavators Model: 211 Engine type: Perkins 4.236 Year: 01.84-12.89
      Daf - Trucks Series: F 1400 Model: FA 1400 DF Engine volume: 6.2 Engine type: DF 615 Year: 01.70-11.81
      FMG Series: Skogsmaskin Model: 910.4 Engine type: Perkins 1000.4
      Gremo Series: Skogsmaskin Model: 950, HPV Engine type: Perkins 1000.6
      Hanomag Model: 20 Series Model series: 22C Size of motor: 4.1 From date: 01-02-1980 Fuel: Diesel Approved: Yes
      Hanomag Model: 30 Series Model series: 33C Size of motor: 5.8 Brand of engine: A6.354.4 From date: 01-07-1980 Fuel: Diesel Approved: Yes
      Hanomag Series: 20-Serie Model: 22 C Engine volume: 4.1 Engine type: Perkins-4.248 Year: 02.80-
      Hanomag Series: 30-Serie Model: 33 C Engine volume: 5.8 Engine type: Perkins-A 6.354.4 Year: 07.80-
      Huddig Model: 760 Engine type: Perkins 1004-4T
      Komatsu Series: Grävmaskin Model: 12HT-1, 15HT-3 Engine type: Perkins Year: 01.88-
      Ösa Series: Skogsmaskin Model: 250 Engine type: Perkins
      Perkins Engines Model: 6.354.4 24V Engine volume: 5.8 Year: 07.87-12.89
      Perkins Model: 6 Model series: 6-354 From date: 01-01-1980 Fuel: Diesel Approved: Yes
      Perkins Model: Various Models Model series: Various Models Fuel: Diesel Approved: Yes
      Ponsse Series: Skogsmaskin Model: HS 10, 15 Engine type: Perkins 1000.6
      Ponsse Series: Skogsmaskin Model: S 10, 15 Engine type: Perkins 1000.6
      Timberjack Series: Skogsmaskin Engine type: 6-cyl Perkins
      1 / 4
